### Apache Airflow version
Other Airflow 2 version (please specify below)
### What happened
When calling Get an XCom entry endpoint, I get a 404 Xcom entry not found
error. All other endpoints are working correctly and the URL is correct. When
I manually go into the airflow webserver and find the relevant dag_run and go
into xcom, I am able to see the xcom keys and values.
Airflow version 2.1.2.
I have tested this in airflow 2.4.2 and this error does not occur, so seems
to be specific to the earlier version.
### What you think should happen instead
Get an XCom entry should work as according to the documentation
### How to reproduce
The airflow task is an instance of: DatabricksSubmitRunOperator
In dag file:
from airflow.providers.databricks.operators.databricks import
DatabricksSubmitRunOperator
def create_databricks_task(task_id, froms, imports, function='', kwargs='',
trigger_rule='all_success'):
"""
Args:
task_id (str): Globally unique name of the task
froms (str): Python package name
imports (str): Module to import
function (str): name of function to run. For scipts this is usually
main.
kwargs (str): Keyword arguments for module
trigger_rule (str): State required for dag to trigger.
Returns:
An instance of the class DatabricksSubmitRunOperator
"""
params = {
'existing_cluster_id': cluster,
'notebook_task': {
'notebook_path': databricks_task_notebook_path,
'base_parameters': {
'from': froms,
'import': imports,
'function': function,
'kwargs': kwargs
}
},
}
return DatabricksSubmitRunOperator(task_id=task_id, json=params,
trigger_rule=trigger_rule,
on_failure_callback=_teams_webhook_post, do_xcom_push=True,
run_name=f"{task_id}--{froms}--{imports}")
# Generate universe
task_id = 'generate_universe'
imports = 'generate_universe'
kwargs = ""
froms = 'scripts.drsk.drsk_universe_creation'
generate_universe = create_databricks_task(task_id=task_id, froms=froms,
imports=imports, kwargs=kwargs)
In databricks it calls this notebook:
import logging
logging.getLogger("py4j").setLevel(logging.WARN)
dbutils.widgets.text("import", '')
dbutils.widgets.text("from", '')
dbutils.widgets.text("kwargs", '')
dbutils.widgets.text("function", '')
imports = dbutils.widgets.get("import")
froms = dbutils.widgets.get("from")
kwargs_str = dbutils.widgets.get("kwargs")
function = dbutils.widgets.get("function")
kwargs={}
_temp = __import__(f'{froms}', globals(), locals(),[f'{imports}'] )
if not function :
result = getattr(_temp, f'{imports}').main(**kwargs)
else:
result = getattr(getattr(_temp, f'{imports}'),f'{function}')(**kwargs)
This should be configured to a databricks environment as per the
documentation.
The airflow API is being accessed in the following way:
import requests
import pandas as pd
auth = (<username>, <password>)
headers = {
"Content-Type": "application/json"
}
url = <airflow_url>
deployment_url = f"http://{url }/api/v1"
def airflow_request(url):
return requests.get(
url=f"{deployment_url}/{url}",
headers=headers,
data='{}',
auth=auth
)
# Get dag run ID
response = airflow_request(f"dags/{dag_id}/dagRuns?offset=100")
json = response.json()
dag_df = pd.DataFrame.from_dict(json['dag_runs'])
# Xcom example
dag_id = 'drsk'
dag_run_id = 'manual__2022-11-21T06:22:17.169771+00:00' # selected from
above endpoiont
task_id = 'generate_universe'
xcom_key = 'run_page_url'
response =
airflow_request(f"/dags/{dag_id}/dagRuns/{dag_run_id}/taskInstances/{task_id}/xcomEntries)
# This endpoint works #correctly and displays all relevant xcom_keys
response =
airflow_request(f"/dags/{dag_id}/dagRuns/{dag_run_id}/taskInstances/{task_id}/xcomEntries/{xcom_key}")
json = response.json()
xcom = pd.DataFrame.from_dict(json['xcom_entries'])
### Operating System
windows 10 for api call, ubuntu 20.04 for airflow
### Versions of Apache Airflow Providers
apache-airflow[crypto,postgres]==2.1.2
apache-airflow-providers-databricks==2.0.0
apache-airflow-providers-microsoft-azure==3.1.0
azure-servicebus
### Deployment
Docker-Compose
### Deployment details
Docker version 20.10.7, build 20.10.7-0ubuntu5~18.04.3
Basic docker-compose deployment
### Anything else
### Are you willing to submit PR?
- [ ] Yes I am willing to submit a PR!
