akashdw opened a new issue #5427: [Proposal] config to allow load segment to physical memory on load URL: https://github.com/apache/incubator-druid/issues/5427 Seeing some of the segments(roughly 30%) in in-memory tier are not loaded to memory as buffer cache and causing page-faults at the **query time**. In our setup, in-memory tier is backed by non-ssd disk which sometimes causes ~100-600 millis to load segments to memory. After debugging I found there is no explicit `MappedByteBuffer.load()` call here https://github.com/druid-io/druid/blob/master/java-util/src/main/java/io/druid/java/util/common/io/smoosh/SmooshedFileMapper.java#L132. I believe not to explicitly load segment decision was made as loading would potentially evict a whole bunch of stuff and it would load up the full segment even if only one column is ever actually used. But in case of **in-memory tier** it would be nice to have a configuration that defaults to `false` to allow `MappedByteBuffer.load()` to load new segments to memory. Server details: Running an in-memory tier, in-memory server `maxSize`=100G, memory available to map ~120G. VM options : ```vm.dirty_ratio = 80, vm.swappiness = 0, vm.dirty_background_ratio = 5.``` Java version: ``` java version "1.8.0_121" Java(TM) SE Runtime Environment (build 1.8.0_121-b13) Java HotSpot(TM) 64-Bit Server VM (build 25.121-b13, mixed mode) ``` Running java historicals with following jvm args: ``` -Xmx6144M -XX:MaxDirectMemorySize=133120M -XX:+HeapDumpOnOutOfMemoryError -XX:HeapDumpPath=/tmp/CD-DRUID-RxOxjYtF_CD-Da1880e55-DRUID_HISTORICAL-1805d8a436c0f10c0f5e57a824d10507_pid46815.hprof -XX:OnOutOfMemoryError=/usr/lib64/cmf/service/common/killparent.sh -server -Djava.net.preferIPv4Stack=true -Duser.timezone=UTC -Dfile.encoding=UTF-8 -Djava.io.tmpdir=/run/cloudera-scm-agent/process/2708-druid-DRUID_HISTORICAL/tmp -Djava.util.logging.manager=org.apache.logging.log4j.jul.LogManager -XX:MaxPermSize=256m -XX:+UseG1GC -XX:+PrintGCDetails -XX:+PrintGCDateStamps -Djute.maxbuffer=0xffffff ``` Wrote a simple java program to debug this (passing segment files as argument): ``` import java.io.File; import java.io.RandomAccessFile; import java.nio.MappedByteBuffer; import java.nio.channels.FileChannel; public class MemoryMappedFile { public static void main(String[] args) throws Exception { File file = new File(args[0]); //Get file channel in readonly mode FileChannel fileChannel = new RandomAccessFile(file, "r").getChannel(); MappedByteBuffer buf = fileChannel.map(FileChannel.MapMode.READ_ONLY, 0, fileChannel.size()); System.out.println(buf.isLoaded()); System.out.println(buf.capacity()); buf = buf.load(); System.out.println(buf.isLoaded()); } } ``` Produces : ``` false 262157890 true true 358945508 true false 284802939 true true 311227380 true ``` output after rerunning the same program: ``` true 262157890 true true 358945508 true true 284802939 true true 311227380 true ``` buffer/cache graph after running above in one of the historical
