Re: [Geoserver-users] Icons in KMZ outputs

[Nil Silva]

Hello.
I decided to try to debug this myself but didn't get very far... So I'm
back for help.

After playing around with kmz files manually I learned that .svg files are
not supported (At least not supported by google earth pro). So I tried to
use a png file instead and got the same result. It works but the icon is
not stored in the kmz file.
I also simplified the layer style to minimise errors on my part there.

The full file is annexed but the important part is, I think, this:

<PointSymbolizer>
  <Graphic>
    <ExternalGraphic>
      <OnlineResource xlink:type="simple" xlink:href="
https://i.ibb.co/nmGm4wj/duck-19415.png"; />
      <Format>image/png</Format>
    </ExternalGraphic>
    <Size>32</Size>
  </Graphic>
</PointSymbolizer>

>From what I can tell in the "encodeAsKmz" method "KMLMapResponse" class here
<https://github.com/geoserver/geoserver/blob/6ad2b678741ef4bf194db38ef13159e46a0a942c/src/kml/src/main/java/org/geoserver/kml/KMLMapResponse.java#L122>
the
"embeddedIcons" is always empty... And have haven't even found where the
variable "iconStyles" from the "KmlEncodingContext" class is set (This is
what "context.getIconStyles()" returns) other than here
<https://github.com/geoserver/geoserver/blob/6ad2b678741ef4bf194db38ef13159e46a0a942c/src/kml/src/main/java/org/geoserver/kml/KmlEncodingContext.java#L133>
.

Thanks.



Nil Silva <nil.silva...@gmail.com> escreveu no dia terça, 16/08/2022 à(s)
17:31:

> I looked around on jira but didn't find this issue so I guess you're
> right. I will open the bug and see what happens. Thank you.
>
>
>
> Nil Silva.
>
>
>
> *From: *Ian Turton <ijtur...@gmail.com>
> *Sent: *16 de agosto de 2022 17:22
> *To: *Nil Silva <nil.silva...@gmail.com>
> *Cc: *geoserver-users <geoserver-users@lists.sourceforge.net>
> *Subject: *Re: [Geoserver-users] Icons in KMZ outputs
>
>
>
> It looks like no one logged the bug,so no one fixed it.
>
> Ian
>
>
>
> On Tue, 16 Aug 2022, 16:12 Nil Silva, <nil.silva...@gmail.com> wrote:
>
> Exporting to kmz doesn't add the icons to the exported kmz. It just has
> the wms.kml file and an empty images folder. The kml file has the image
> url. It looks like the same problem from the following mailing list
> messages.
>
>
>
> https://sourceforge.net/p/geoserver/mailman/message/37133697/
>
>
>
> From the looks of it it seems like a bug.
>
> Has it not been fixed or is this a problem on my end?
>
>
>
> Thanks,
>
> Nil Silva.
>
> _______________________________________________
> Geoserver-users mailing list
>
> Please make sure you read the following two resources before posting to
> this list:
> - Earning your support instead of buying it, but Ian Turton:
> http://www.ianturton.com/talks/foss4g.html#/
> - The GeoServer user list posting guidelines:
> http://geoserver.org/comm/userlist-guidelines.html
>
> If you want to request a feature or an improvement, also see this:
> https://github.com/geoserver/geoserver/wiki/Successfully-requesting-and-integrating-new-features-and-improvements-in-GeoServer
>
>
> Geoserver-users@lists.sourceforge.net
> https://lists.sourceforge.net/lists/listinfo/geoserver-users
>
>
>

layer_style.sld
Description: Binary data
